Schneider A9Z01425 Acti 9 ID K RCCB 4P 25A 30mA Type A

The Schneider Electric A9Z01425 is a 4-pole residual current circuit breaker (RCCB) from the Acti 9 ID K range, suited for downstream protection in AC distribution systems. It provides instantaneous tripping at 30 mA residual-current sensitivity.

• Reference: A9Z01425
• Poles: 4P, neutral position left
• Rated current [In]: 25 A
• Residual current sensitivity: 30 mA, Type A, instantaneous
• Rated voltage [Ue]: 380...415 V AC 50 Hz
• Impulse withstand voltage [Uimp]: 4 kV
• Conditional short-circuit current: Inc 4.5 kA (GL63) / Inc 6 kA (K60)
• Mounting: Clip-on DIN rail, 8 × 9 mm modules; height 81 mm, depth 68 mm
• Cable connections: 1...35 mm² solid / 1...25 mm² flexible; tightening torque 3.5 N.m
