2CDS272061R0104 ABB S202M-C10UC MCB 2P C10A 10kA UC S200M

The ABB S202M-C10UC (article 2CDS272061R0104) is a 2-pole miniature circuit breaker rated at 10 A with a C trip characteristic, part of the ABB System pro M compact® product family. It provides overcurrent and short circuit protection with a breaking capacity of 10 kA (AC) and is designed to operate in both AC and DC applications within a single device.

Technical specifications:

• Series: S200MUC (S 200 M UC)
• ABB article number: 2CDS272061R0104
• EAN: 4013614432996
• Poles: 2P
• Rated current: 10 A
• Trip characteristic: C
• Short circuit breaking capacity (AC): 10 kA
• Application compatibility: AC and DC

Features and benefits:

• Operates on both AC and DC circuits, reducing the need for separate breakers in installations that combine both supply types
• 10 kA short circuit breaking capacity (AC) is maintained consistently across the entire S 200 M UC model range
• Fully compatible with all existing ABB System pro M compact® accessories, allowing direct integration into current panel builds
• Approved and compliant with major international and local standards, supporting deployment across diverse markets and project types
• Covers warehousing, project engineering, installation, and maintenance scenarios from a single product line

Applications:

• Overcurrent and short circuit protection in residential and commercial distribution boards
• Circuit protection in DC power systems, including battery storage and similar low-voltage DC installations
• Industrial control panels requiring dual AC/DC protection capability
• Building electrical installations already using ABB System pro M compact® infrastructure

Also known as: ABB S202M-C10UC, S202M-C10UC 2CDS272061R0104, ABB 2CDS272061R0104, 2-pole 10 A C-curve MCB, ABB S200M UC miniature circuit breaker.
