1SNL308010R0000 ABB DBL80 Distribution Block 80A 1000V 1+4 Pole Grey

1SNL308010R0000 ABB DBL80 is a single-pole power distribution block (busbar block) for branching one main supply into multiple outgoing circuits in industrial control panels and distribution boards. The screw-clamp box-lug terminals accept one input conductor and four output conductors per pole, with full enclosure cover for finger-safe operation.

Technical specifications:

• Part number: 1SNL308010R0000
• Manufacturer: ABB (Entrelec)
• Series: DBL Power Distribution Block
• Rated current (Ie): 80 A
• Rated working voltage (Ue): 1000 V AC
• Rated insulation voltage (Ui): 1.5 kV
• Rated impulse voltage (Uimp): 8 kV
• Rated peak withstand current (Ipk): 27 kA
• Configuration: 1-pole, 1 input + 4 outputs
• Input wire range: 3 x 14-4 AWG (up to 16 mm2 copper)
• Output wire range: 4 x 14-10 AWG
• Connection: Box-lug screw clamp
• Housing: Polyamide, grey, self-extinguishing V0
• Mounting: DIN rail (35 mm)
• Cover: Transparent, IP20, included

Features and benefits:

• Compact 1-pole format saves DIN rail and panel space versus separate terminal blocks
• Box-lug terminals accept stranded and solid conductors without ferrules
• Included transparent cover provides IP20 finger-safe protection per IEC 60529
• Polyamide housing rated V0 for self-extinguishing flame retardancy
• Direct DIN rail clip-on mounting, no tools required for installation

Applications:

• Power distribution in industrial control cabinets and machine panels
• Branching mains supply to multiple motor protection or breaker outputs
• Service entrance distribution in commercial panels
• Solar inverter and PV combiner box DC distribution
• Replacement for hand-built busbar arrangements

Standards: UL 1059, IEC 60947-7-1, CSA, RoHS compliant.

Also known as: ABB DBL80 distribution block, Entrelec DBL80, 1 input 4 output power distribution terminal, 80A busbar block, single-pole distribution block.
