Schneider EPH0200171 Asfora 2-Pole Switch 10AX Screwless Anthracite Insert

Overview

The Schneider Electric EPH0200171 is an Asfora 2-pole 1-way wall switch insert in anthracite finish. Supplied as a mechanism with fixing frame and rocker cover plate (no decorative outer frame); pair it with a separately ordered Asfora decorative frame to complete the installation. Both line and neutral are switched. Screwless push-in terminals; rated 10 AX at 250 V AC.

Key Specifications

• Range: Asfora
• Type: Wall switch insert, 2-pole 1-way (double-pole)
• Number of rockers: 1
• Presentation: Mechanism with fixing frame and cover plate (decorative outer frame not included)
• Actuator: Rocker, flush mounting
• Rated current: 10 AX at 250 V AC
• Power range: 2300 W
• Energy-saving lamp load (with ballast): up to 100 W
• Terminals: Screwless push-in, 2 x 2.5 mm² (rigid / flexible / solid stranded), 13 mm strip
• Conductor material: Copper
• Fixing: Screws or claws, 51...70 mm centres
• Material: ABS, painted
• Colour: Anthracite
• Dimensions: 71 x 71 x 43 mm (H x W x D), projecting depth 15 mm
• Weight: 61.1 g
• IP20; operating temperature -5...40 °C
• Standards: IEC 60669-1; certifications TSE, VDE, NF; CE, UKR labels
• Warranty: 18 months

Typical Applications

• Bathrooms and damp locations where double-pole isolation is required
• Boiler, water heater and high-load lighting circuits
• Workshops, garages and outbuildings where full isolation of the load is needed
• Modern interiors using the Asfora anthracite finish

Compliance

IEC 60669-1. CE marked. Schneider Electric Asfora wiring devices range.
