Telemecanique ZCKD41 XC Standard Limit Switch Head Variable-Length Roller Lever

The Telemecanique ZCKD41 is a limit switch head from the Limit switches XC Standard range, designed to pair with XCKS, XCKL, and XCKM series limit switch bodies. It uses a rotary head with a thermoplastic roller lever that is adjustable to variable length with spring return, actuated by a 30° cam via lateral approach from 2 directions. The head operates across an ambient temperature range of -25...70 °C in standard environments.

Technical specifications:

• Catalog reference: ZCKD41
• Manufacturer: Telemecanique (Schneider Electric)
• Product type: Limit switch head
• Series: Limit switches XC Standard
• Head type: Rotary head
• Operator type: Roller lever, spring return, thermoplastic, adjustable variable length
• Approach type: Lateral, 2 directions
• Switch actuation: By 30° cam
• Positive opening: Without
• Head material: Plastic
• Environmental characteristic: Standard environment
• Operating temperature: -25...70 °C
• Storage temperature: -40...70 °C
• Weight: 95 g
• Dimensions (H x W x L): 3.5 cm x 6.4 cm x 9.9 cm
• Compatible bodies: ZCKM, ZCKL, ZCKS, ZCKSD, ZCKLD, ZCKMD series
• Warranty: 18 months

Features and benefits:

• Adjustable variable-length roller lever adapts to different cam geometries and mounting configurations without additional parts.
• Spring return mechanism ensures reliable actuator reset after each operation cycle.
• Lateral approach from 2 directions allows flexible machine mounting where axial access is restricted.
• Wide operating temperature range of -25...70 °C covers standard industrial environments.
• Green Premium product status under Schneider Electric's sustainable offer programme, with no special recycling operations required.

Applications:

• End-of-travel detection on linear axes and conveyor systems.
• Position sensing on machine guarding doors and safety interlocks.
• Cam-actuated position detection on packaging and assembly machinery.
• Limit control on material handling equipment requiring lateral actuation.

Also known as: Telemecanique ZCKD41, ZCK limit switch head, XC Standard roller lever actuator head.
