Schneider Electric LVS04200 Earth bar camps L450 linergy TB

The Schneider Electric LVS04200 is a Linergy TB earth busbar supplied as an earthing accessory for use within PrismaSeT G and PrismaSeT P enclosures. The 450 mm bar provides 40 standard connections plus one 35 mm² connection.

• Product Group: Linergy TB
• Connections: 40 standard connections + 1 × 35 mm² connection
• Length: 450 mm
• Width: 13 mm
• Depth: 12 mm
• Weight: 0.36 kg
• Colour: Natural
• Compatible Enclosures: PrismaSeT G, PrismaSeT P
• Installation: Free-standing enclosure (600 mm width), wall-mounted enclosure (600 mm width), enclosure (650 mm width), Pack enclosure (550 mm width)
• Quantity per Set: 1
• EU RoHS: Compliant
• REACh: Declaration available
• Halogen Content: Halogen-free plastic parts; PVC-free
• Packaging: Recycled cardboard; plastic-free
