Schneider Electric C106TM100 TM100D for ComPacT NSX 100/160/250 Circuit Breakers, thermal magnetic, rating 100 A, 4P

The Schneider Electric C106TM100 is a TM-D thermal-magnetic trip unit compatible with ComPacT NSX 100, NSX 160, and NSX 250 new-generation circuit breakers, intended for power distribution applications.

• Trip unit rating: 100 A at 40 °C
• Rated voltage (Ue): 690 V AC, 50/60 Hz
• Poles: 4P; 3 poles protected (3d) — neutral not protected
• Neutral conductor position: Left
• Protection functions: L – thermal overload; I – short-circuit
• Long-time pick-up (Ir): Adjustable, 0.7–1 × In
• Long-time protection delay (tr): 120–400 s at 1.5 × In; 15 s at 6 × Ir
• Instantaneous pick-up (Ii): Fixed at 800 A
• Mounting mode: Fixed
• Standard: EN/IEC 60947-2
• Degree of protection: IP40 per IEC 60529
• Pollution degree: 3 per IEC 60947-1
• Operating ambient temperature: −25 to +70 °C
• Storage temperature: −50 to +85 °C
