Eaton 171466 SL7-L24-A Continuous Light Module Orange LED 24V

The Eaton 171466 is a Moeller series SL7 continuous light module fitted with an orange LED and rated 24 V AC or DC. It provides a steady (continuous) light function in a black enclosure and forms part of the SL7 signal tower system.

Technical specifications:

• Catalog number: 171466
• Model code: SL7-L24-A
• Manufacturer: Eaton
• EAN: 4015081677931
• Series: Eaton Moeller series SL7
• Product type: Continuous light module
• Function: Continuous light
• Light source: LED
• Colour: Orange
• Enclosure colour: Black
• Rated operational voltage (Ue) AC: 24 V
• Rated operational voltage (Ue) DC: 24 V
• Rated insulation voltage (Ui): 250 V
• Leakage current: 0.003 A
• Ambient operating temperature: -30 °C to +60 °C
• Dimensions (L x H x W): 73 x 73 x 73 mm
• Weight: 0.08 kg
