Schelinger A02-G7-1P-C25 Overcurrent Circuit Breaker 1P C25A
by SCHELINGER
Free Shipping
Get free shipping on orders exceeding €300!
Original price
€1,33
-
Original price
€1,33
Original price
€1,33
€1,33
-
€1,33
Current price
€1,33
The Schelinger A02-G7-1P-C25 is a 1P miniature circuit breaker (MCB) with a C tripping curve, rated 25 A with a breaking capacity of 4.5 kA. It is a modular device 1 module wide.
Technical specifications:
- Manufacturer part number: A02-G7-1P-C25
- Brand: Schelinger (BEMKO)
- Poles: 1P
- Rated current: 25 A
- Tripping curve: C
- Breaking capacity: 4.5 kA
- Rated voltage: 230/400V AC 50/60Hz
- Rated insulation voltage (Ui): 415V
- Rated impulse withstand voltage (Uimp): 4kV
- Energy limitation class: 1
- Terminal capacity: max 25mm²
- Protection rating: IP20
- Width: 1 module (17.5 mm)
- Dimensions (W x H x D): 17.5 x 81 x 69 mm
- Operating temperature: -5 to +30°C
- Standard: EN 60898-1
Also known as: Schelinger A02-G7-1P-C25, G7-1P-C25.
