Schelinger A02-G7-1P-C16 Overcurrent Circuit Breaker 1P C16A
by SCHELINGER
Free Shipping
Get free shipping on orders exceeding €300!
Sold out
Original price
€1,24
-
Original price
€1,24
Original price
€1,24
€1,24
-
€1,24
Current price
€1,24
The Schelinger A02-G7-1P-C16 is a 1P miniature circuit breaker (MCB) with a C tripping curve, rated 16 A with a breaking capacity of 4.5 kA. It is a modular device 1 module wide.
Technical specifications:
- Manufacturer part number: A02-G7-1P-C16
- Brand: Schelinger (BEMKO)
- Poles: 1P
- Rated current: 16 A
- Tripping curve: C
- Breaking capacity: 4.5 kA
- Rated voltage: 230/400V AC 50/60Hz
- Rated insulation voltage (Ui): 415V
- Rated impulse withstand voltage (Uimp): 4kV
- Energy limitation class: 1
- Terminal capacity: max 25mm²
- Protection rating: IP20
- Width: 1 module (17.5 mm)
- Dimensions (W x H x D): 17.5 x 81 x 69 mm
- Operating temperature: -5 to +30°C
- Standard: EN 60898-1
Also known as: Schelinger A02-G7-1P-C16, G7-1P-C16.
When sold out, you can still preorder by requesting a quote below.
Important
The images shown are for illustration purposes only and may not be an exact
representation of the product.
