Phoenix Contact 3026366 SB 2-8-T Bridge bar 8.2mm 2-Way Orange

The Phoenix Contact SB 2-8-T is a 2-position plug-in bridge bar with an 8.2 mm pitch, designed to electrically parallel adjacent terminal blocks in a single operation. Its copper conductor body with a polyamide (PA) insulating sleeve delivers a secure, low-resistance connection across one potential. The compact 15.3 x 15.6 x 15.6 mm profile makes it well suited for dense DIN rail installations.

Technical specifications:

• Part designation: SB 2-8-T
• Catalog number: 3026366
• Manufacturer: Phoenix Contact
• EAN: 4017918351229
• Number of positions: 2
• Pitch: 8.2 mm
• Potentials: 1
• Color: orange (RAL 2003)
• Conductor material: Copper
• Insulating material: Polyamide (PA)
• Dimensions (W x H x D): 15.3 mm x 15.6 mm x 15.6 mm
• Weight (excl. packing): 2.7 g
• Weight (incl. packing): 3.75 g
• Operating temperature: -60 °C ... 105 °C
• Storage temperature: -25 °C ... 60 °C
• Assembly temperature: -5 °C ... 70 °C
• Mounting type: Plug-in
• Country of origin: Poland (PL)
• Pack size: 10 pc

Features and benefits:

• Plug-in mounting allows fast, tool-free installation across two terminal block positions
• Copper conductor ensures low-resistance electrical bridging between adjacent positions
• Wide operating temperature range (-60 °C to 105 °C) suits demanding industrial environments
• Orange color (RAL 2003) provides clear visual identification of bridged potential groups
• EU RoHS compliant with no exemptions; REACH SVHC substances below 0.1 wt%
• Compact dimensions allow use in space-constrained control cabinets and enclosures

Applications:

• Paralleling two adjacent terminal blocks on DIN rail assemblies
• Grouping potential connections in industrial control panels and switchgear
• Signal and power distribution in automation and process control systems
• Building installation distribution boards requiring grouped terminal bridging
• Machine control cabinets where quick reconfiguration of potential groups is needed

Compliant with EU RoHS (no exemptions) and EU REACH SVHC requirements. Sold in packs of 10 pieces (minimum order quantity: 10 pc).

Also known as: Phoenix Contact SB 2-8-T, Phoenix 3026366, Phoenix Contact 2-position bridge bar, SB2-8-T bridge connector.
