Telemecanique XS612B1MAL2 XS6 Inductive Sensor M12 Sn 4mm 24-240V AC/DC 2m

The Telemecanique XS612B1MAL2 is an XS6 inductive proximity sensor in a flush-mountable M12 nickel-plated brass body, 54 mm long. It has a 4 mm nominal sensing distance, a 2-wire NO output for 24 to 240 V AC/DC and a 2 m PVC cable.

Technical specifications:

• Part number: XS612B1MAL2
• Series: XS6, general purpose
• Body: cylindrical M12 x 1, nickel-plated brass, length 54 mm, threaded length 42 mm
• Mounting: flush
• Front material: PPS
• Nominal sensing distance Sn: 4 mm (operating zone 0 to 3.2 mm)
• Output: 2-wire, 1 NO, AC/DC
• Rated supply voltage: 24 to 240 V AC/DC, 50/60 Hz (limits 20 to 264 V)
• Switching capacity: 5 to 200 mA
• Switching frequency: up to 1000 Hz DC, 25 Hz AC
• Maximum voltage drop: below 5.5 V (closed)
• Maximum residual current: 0.8 mA (open)
• Status LED: yellow, output state
• Connection: 2 m cable, 2 x 0.34 mm², PVC
• Degree of protection: IP68 double insulation (IEC 60529), IP69K (DIN 40050)
• Operating temperature: -25 to 70 °C
• Certifications: UL, CSA, CE marking
• Net weight: 0.075 kg
