Schneider SDD113411 Sedna Loudspeaker Socket 2-Way Aluminium

Overview

The Schneider SDD113411 is a Sedna Design & Elements flush loudspeaker socket in aluminium, with two stereo speaker outputs on the front. It is supplied as a mechanism with fixing frame and central plate, and provides a tidy in-wall termination for a stereo pair of speakers connected back to an amplifier or AV receiver.

Key features

• Two-channel loudspeaker socket (left/right, red and black terminals) for a stereo speaker pair.
• Screwless push-in terminals accept rigid or flexible 1.5 mm² speaker cable with a 7 mm strip.
• UV-stabilised ABS body with matt aluminium finish (RAL 7047 / RAL 9006).
• Standard 73 x 73 mm flush module, fits Sedna and compatible 71 mm frames.
• Adjustable claws (51...70 mm or 52...71 mm) and screw fixing for installation flexibility.

Technical specifications

• Range: Sedna Design & Elements
• Function: Loudspeaker socket
• Device presentation: Mechanism with fixing frame and central plate
• Socket number: 2
• Colour: Aluminium (RAL 9006 / RAL 7047)
• Terminals: Screwless, 1 cable 1.5 mm² per terminal
• Wire stripping length: 7 mm
• Wire structure: Rigid or flexible
• Material: Thermoplastic ABS-UV stabilised
• Surface finish: Matt
• Device mounting: Flush
• Fixing mode: Claws 51...70 mm or 52...71 mm, plus screws
• Dimensions (W x H x D): 73 x 73 x 53 mm
• Visible part depth: 31 mm
• Product weight: 0.058 kg
• IP degree of protection: IP20
• Warranty: 18 months

Applications

Used in living rooms, home cinemas, hotel rooms and meeting rooms where a stereo speaker pair is wired into the wall and needs a clean wall-plate termination instead of bare cable. Suitable for use behind sofas, beside AV cabinets and at the speaker end of a wall-buried cable run.
