Schneider Electric A9D67416 IC60 Residual current Circuit Breaker with overcurrent protection 4P C16A 30mA

The Schneider Electric A9D67416 is a 4-pole residual current breaker with overcurrent protection (RCBO) from the Acti9 iC60 range, rated at 16 A with a C trip curve and 30 mA Type A earth-leakage protection. It is intended for outgoer distribution applications on 380–415 V AC 50 Hz networks.

• Poles and rated current: 4P, 16 A, C curve; magnetic tripping threshold 5–10 × In
• Earth-leakage protection: 30 mA, Type A, instantaneous, integrated, voltage-independent
• Rated operational voltage (Ue): 380–415 V AC, 50 Hz
• Breaking capacity: 6,000 A Icn at 380–415 V AC 50 Hz (EN/IEC 61009-2-1); 6 kA Icu (EN/IEC 60947-2); limitation class 1
• Rated insulation voltage (Ui): 500 V AC, 50 Hz
• Rated impulse withstand voltage (Uimp): 4 kV; surge current 250 A (8/20 µs impulse, EN/IEC 61009-2-1)
• Overvoltage category: III (IEC 60364); IP40 in distribution enclosure / IP20 (IEC 60529)
• Mounting: Clip-on, DIN rail; 9 mm connection pitch between poles; compatible with comb busbar top or bottom
• Terminals: Tunnel type, top or bottom — 1–35 mm² rigid, 1–25 mm² flexible, 1–25 mm² flexible with ferrule; wire stripping length 12 mm; tightening torque 2 N·m
• Dimensions (H × W × D): 86 × 72 × 78 mm; weight 423 g; colour white
• Operating temperature: −25 to +60 °C; storage −40 to +70 °C; tropicalisation 95 % at 55 °C
• Durability: 20,000 mechanical cycles; 10,000 electrical cycles
• Standards: EN/IEC 61009-2-1, EN/IEC 60947-2
• Quality approvals: VDE, NF, IMQ, KEMA-KEUR
