Schneider Electric A9C20132 iCT 25A 2NO 24V 50Hz contactor

The Schneider Electric A9C20132 is a 2-pole, 25 A AC contactor from the Acti 9 iCT range, intended for remote control of motor, heating, and cooling circuits. It operates on a 24 V AC 50 Hz control circuit and carries two normally open (NO) contacts, mounting directly onto a 35 mm symmetrical DIN rail via a snap-on mechanism.

• Rated current [Ie]: 25 A (AC-7A) / 8.5 A (AC-7B)
• Poles: 2P, 2 NO contact configuration
• Control circuit voltage [Uc]: 24 V AC, 50 Hz
• Rated voltage [Ue]: 250 V AC, 50 Hz
• Rated insulation voltage [Ui]: 500 V AC, 50/60 Hz
• Rated impulse withstand voltage [Uimp]: 4 kV
• Mechanical endurance: 1,000,000 cycles
• Electrical endurance: 100,000 cycles at 25 A AC-7A (IEC/EN 61095); 30,000 cycles at 8.5 A AC-7B
• IP rating: IP20 per IEC 60529; IP40 when installed in a modular enclosure
• Mounting: 35 mm symmetrical DIN rail, snap-on
• Dimensions (H × W × D): 81 × 18 × 68.5 mm
• Operating temperature: −5 to +60 °C
• Standard: IEC/EN 61095
• Colour: White
