Schneider ABL8RPS24100 Regulated Switch Power Supply, ABL8 Modicon 24VDC 140W 10

The Schneider Electric ABL8RPS24100 is a regulated switch mode power supply (SMPS) from the Modicon Power Supply ABL8 range, delivering a stable 24 V DC output at 10 A from a universal AC input of 100 to 500 V. Rated at 240 W with 87% efficiency, it suits industrial automation and control panel applications requiring reliable regulated DC power.

Technical specifications:

• Commercial reference: ABL8RPS24100
• Manufacturer: Schneider Electric
• EAN:
• Series / range: Modicon Power Supply (ABL8)
• Product type: Regulated switch mode power supply (SMPS)
• Nominal input voltage: 100...120 V AC single-phase (N-L1) / 200...500 V AC phase-to-phase (L1-L2)
• Input voltage limits: 85...132 V AC / 170...550 V AC
• Output voltage: 24 V DC, adjustable 24...28.8 V
• Output current: 10 A
• Rated power: 240 W
• Allowable temporary current: 1.5 x In for 4 s
• Efficiency: 87%
• Power dissipation: 31 W
• Output protection: overload, overvoltage (30...32 V manual reset), short circuit, undervoltage (trips if U below 21.6 V), thermal
• Harmonic filter: power factor correction per IEC 61000-3-2
• SELV supply per IEC 60950-1, IEC 60204-1, IEC 60364-4-41
• Connection terminals: screw terminals, input 3 x 0.5...3 x 4 mm² (AWG 22-12), output 4 x 0.5...4 x 4 mm² (AWG 22-12)
• Status indicators: 2 LEDs - output voltage (green/red) and output current (green/red/orange)
• Mounting: 35 x 7.5 mm or 35 x 15 mm symmetrical DIN rail, vertical mounting position
• Output connection: series or parallel (max 2 units)
• Dimensions (W x H x D): 86 x 125 x 145 mm
• Weight: 1 kg
• IP rating: IP20 per IEC 60529
• Operating temperature: -25...50°C without derating / 50...60°C with derating, altitude up to 2000 m
• Standards: UL 508, CSA C22.2 No 60950-1, EN/IEC 62368-1
• Certifications: UL, CCSAus, EAC, KC, RCM, CE

Features and benefits:

• Universal input range of 100 to 500 V AC, single-phase or phase-to-phase, supports flexible global deployment without reconfiguration
• Built-in power factor correction filter meets IEC 61000-3-2 harmonic emission limits, reducing network disturbance
• Adjustable output voltage (24...28.8 V) allows compensation for long cable voltage drops
• Comprehensive output protection with manual or automatic reset options for overload and short circuit conditions
• Series and parallel output connection of up to two units enables increased voltage or current capacity

Applications:

• Industrial automation control panels and PLC power supply rails
• Machine control cabinets requiring stable 24 V DC distribution
• Process control systems and field device power networks
• Building automation and HVAC control panels

Compliant with UL 508, EN/IEC 62368-1, EN/IEC 61204-3, IEC 61000-6-1, IEC 61000-6-3, IEC 61000-6-4, and IEC 60950-1. Part of the Schneider Electric Modicon Power Supply ABL8 range.

Also known as: Schneider ABL8RPS24100, Schneider Electric ABL8RPS24100, Phaseo ABL8 24V 10A power supply, DIN rail SMPS 24VDC.
