Schneider SDD313805 Sedna Design 5-Gang Cover Frame Aluminium

The Schneider Electric SDD313805 is a 5-gang cover frame from the Sedna Design & Elements range in matt painted aluminium (RAL 7047). It clips onto five adjacent Sedna mechanisms in a single line and accepts both IP20 and IP44 inserts, providing a clean continuous finish for large control panels, AV walls and multi-circuit installations.

Technical specifications

• Range: Sedna Design & Elements (Design aesthetic)
• Product type: Cover frame, 5 gangs
• Installation: Flush, horizontal or vertical orientation
• Fixing mode: Clip-in onto Sedna mechanisms
• Material: Thermoplastic ABS-UV stabilised, matt painted
• Colour: Aluminium (RAL 7047)
• Dimensions: 370 x 85 x 10 mm
• Weight: 0.037 kg
• Protection: IP20, IK02
• Certifications: FIMKO, SEMKO, NEMKO, VDE, AENOR

Features and benefits

• Snap-fit clip-in installation onto five SDD113 / SDD213 mechanisms in a row
• One frame fits both IP20 and IP44 inserts in any combination
• Reversible horizontal or vertical mount for matching adjacent device lines
• Matt painted aluminium finish for a discreet contemporary look
• UV-stabilised ABS retains colour over time

Applications

• Large multi-circuit lighting control panels and socket banks
• Home cinema and AV walls with multiple sockets and USB outlets
• Hotel rooms, conference rooms and offices needing a single continuous finish
