Schneider Electric ZB4BA2 Harmony 22mm Push Button flush push button head spring return black unmarked
Free Shipping
Get free shipping on orders exceeding €300!
Original price
$4.89
-
Original price
$4.89
Original price
$4.89
$4.89
-
$4.89
Current price
$4.89
The Schneider Electric ZB4BA2 is a black, flush-profile, unmarked push button head from the Harmony XB4 range, designed for non-illuminated 22.5 mm panel-mount push button assemblies with spring return action. The body is chrome-plated metal, suitable for demanding industrial control and switching applications.
- Product range: Harmony XB4
- Mounting diameter: 22.5 mm
- Head profile & colour: Flush (recessed), black, unmarked
- Return type: Spring return
- Body material: Chrome-plated metal
- Mechanical endurance: 10,000,000 operating cycles
- Operating & storage temperature: −40 to +70 °C
- IP protection: IP66, IP67, IP69, IP69K (IEC 60529)
- IK impact rating: IK06 (IEC 50102)
- NEMA ratings: NEMA 4X, NEMA 13
- Standards: IEC 60947-5-1, IEC 60947-5-4, IEC 60947-5-5, IEC 60947-1, UL 508, CSA C22.2 No 14, JIS C8201-5-1, JIS C8201-1
- Certifications: BV, CSA, DNV, LROS (Lloyd's Register of Shipping), UL
- Vibration & shock resistance: 5 gn at 2–500 Hz (IEC 60068-2-6); 30 gn / 18 ms and 50 gn / 11 ms (IEC 60068-2-27)
