Schneider EPH6800169 Asfora Rotary Dimmer Multiwire LED 230V 370W Without Frame,

The Schneider Electric EPH6800169 is a rotary dimmer from the Asfora range, designed for Multiwire installation without a frame, in a bronze finish. It supports resistive, LED, and capacitive loads up to 370W at 230V AC, making it a versatile solution for modern lighting control in residential and light commercial environments.

Technical specifications:

• Commercial reference: EPH6800169
• Manufacturer: Schneider Electric
• EAN:
• Series / range: Asfora
• Product type: Dimmer
• Device presentation: Mechanism with mounting frame
• Load type: Resistive: 3-370 W; LED lamp: 0-200 W; Capacitive: 3-370 VA
• Rated voltage: 230V AC 50/60 Hz
• Control type: Rotary knob
• Switch function: Single-pole alternating
• Protection: Short circuit and overload protection with automatic reset
• Colour shade: Bronze
• Finish: Matte
• Material: ABS (acrylonitrile-butadiene-styrene) - centre plate and rotary button
• Connection type: Ferrule terminal; Screw terminal
• Number of cables: 2 cables, 1.5-2.5 mm²
• Cable rigidity: Rigid, flexible, single-wire, multi-wire
• Wire stripping length: 8 mm
• Conductor material: Copper
• Fixing method: With screws and clips
• Width: 71 mm
• Height: 71 mm
• Depth: 47 mm
• Design depth: 29 mm
• Product weight: 0.099 kg
• IP protection rating: IP20
• Certifications: VDE, CE
• Mounting: Flush-mounted

Features and benefits:

• Compatible with resistive, LED, and capacitive loads for broad lighting application coverage
• Rotary knob control provides smooth and intuitive dimming adjustment
• Built-in short circuit and overload protection with automatic reset for added safety
• Accepts both rigid and flexible copper conductors up to 2.5 mm²
• Matte bronze finish offers a premium aesthetic suited to modern interiors
• Compact flush-mount design with 29 mm installation depth for standard back boxes

Applications:

• Residential living room and bedroom lighting control with dimmable LED or incandescent fixtures
• Light commercial spaces requiring adjustable ambient lighting, such as offices and reception areas
• Hospitality environments where scene-setting and energy-efficient dimming are required
• New build and renovation projects using Multiwire wiring systems

Compliant with VDE certification requirements and CE marking. Part of the Schneider Electric Asfora range.

Also known as: Schneider EPH6800169, Schneider Electric EPH6800169, Asfora rotary dimmer, Schneider Multiwire LED dimmer.
