LV431411 Circuit breaker basic frame, ComPact NSX250N, 50kA at 415VAC 50/60 Hz, 250A, without trip unit, 4 poles
Free Shipping
Get free shipping on orders exceeding €300!
This is a 4 poles basic frame for Compact NSX250N. Compact NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit which has to be ordered separately The breaking capacity Icu is 50kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 140mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX250N is part of Schneider Electric EcoStruxure Power architecture.
Für EU-Kunden sind die Preise inklusive Mehrwertsteuer sichtbar. Geschäftskunden kontaktieren Sie uns bitte oder melden Sie sich an, um von der Steuerbefreiung zu profitieren.
When sold out, you can still preorder by requesting a quote below.
Wichtig
Die gezeigten Bilder dienen nur zur Veranschaulichung und sind möglicherweise nicht genau
Darstellung des Produkts.
