Knipex 12 74 180 Automatic Cable Stripping Pliers 175 mm

The Knipex 12 74 180 is a 175 mm automatic cable stripping tool for removing the outer sheath of flexible supply cables, extension cables, and control and sensor/actuator cables. It self-adjusts to cable diameters from 4.4 mm to 7.0 mm without damaging inner conductors or shielding braid. A maintenance-friendly blade block allows fast blade replacement, and an ergonomic two-component handle minimises operator effort during repeated use.

Specifications:

• Part number: 12 74 180
• Manufacturer: Knipex
• EAN: 4003773092667
• Product type: Automatic cable stripping pliers
• Overall dimensions: 175 x 98 x 30 mm
• Weight: 145 g
• Stripping range (diameter): 4.4 - 7.0 mm
• REACH: Contains no SVHC
• RoHS: Not applicable

Features and benefits:

• Designed for stripping the outer sheath of flexible supply cables, extension cables, and control and sensor/actuator cables
• Automatic adjustment to cable diameters from 4.4 mm to 7.0 mm with no damage to conductors or shielding braid
• Maintenance-friendly blade block allows fast blade replacement when blades become worn
• Compatible with cable sheaths made from highly flexible TPE-U, PUR, PVC and rubber, including oil-resistant and halogen-free control and sensor/actuator cables
• Cable can be fed through the tool, making it suitable for longer stripping lengths
• Ergonomic two-component handle with soft grip zone for low-stress work and maximum force transfer
• Smooth-running mechanism reduces the effort required during operation

Applications:

• Stripping the outer jacket from flexible supply leads and extension cables during electrical installation work
• Preparing control cables and sensor/actuator cables for panel wiring and automation systems
• Machine building and industrial wiring tasks requiring clean, consistent jacket removal
• Electrical maintenance and repair work involving repeated cable preparation
• Processing halogen-free and oil-resistant cable types in demanding industrial environments

Also known as: Knipex 12 74 180, Knipex 1274180, Knipex 1274180 automatic wire stripper, automatic cable jacket stripper 175 mm.
