Siemens 5SU1324-7FA06 SENTRON RCBO 2P Type A C 6A 30mA 10kA

The Siemens 5SU1324-7FA06 is a SENTRON 2-pole RCBO (residual current circuit breaker with overcurrent protection) rated 6 A on a C tripping characteristic with 30 mA Type A residual current detection. It combines earth-leakage and overload/short-circuit protection in a single 1-module device, switching both phase and neutral simultaneously.

Technical specifications:

• Order number (MLFB): 5SU1324-7FA06
• Manufacturer: Siemens
• Product line: SENTRON
• Product type: RCBO (instantaneous design)
• Number of poles: 2 (both poles protected; 1P+N functionality with neutral switching)
• Tripping characteristic: C
• Rated current (In): 6 A
• Tripping fault current (IΔn): 30 mA
• Residual current type: A (detects AC and pulsating DC fault currents)
• Short-circuit breaking capacity:
  • 10 kA per EN 60898
  • 35 kA per IEC 60947-2
  • 10 kA Icn per EN 61009-1
  • 10 kA Im residual switching capacity per IEC 61009-1
• Energy limitation class: 3
• Supply voltage: 230/240 V AC, 50 Hz
• Test voltage (min): 195 V AC
• Insulation voltage (Ui): 264 V
• Surge voltage resistance: 4 kV
• Surge current resistance (8/20 µs): 1 kA
• Overvoltage category: III
• Pollution degree: 2
• Derated operational current: 5.7 A @ 40 °C; 5.4 A @ 50 °C; 4.86 A @ 65 °C; 4.62 A @ 70 °C
• Power loss: max 3.7 W
• Mechanical service life: 10,000 operating cycles
• Touch protection: Yes
• Neutral conductor switching: Yes
• Halogen-free: Yes
• Silicon-free: Yes
• IP protection: IP20 with connected conductors when installed in distribution board
• Conductor range: 0.75-35 mm² (solid/stranded), 0.75-25 mm² (finely stranded with end-sleeve)
• Tightening torque: 2.5-3 N·m
• Power supply position: top or bottom
• Height: 90 mm; Width: 54 mm (3 modules)
• Standards: IEC/EN 61009-1, IEC/EN 60947-2
• EAN/GTIN: 4001869305882

Features and benefits:

• All-in-one earth-leakage + overcurrent protection in 3-module width - fewer devices per final circuit
• Type A residual current detection - reliably trips on pulsating DC faults from rectifiers, switching power supplies and inverter loads
• 10 kA EN 60898 / 35 kA IEC 60947-2 breaking capacity - usable in both residential and industrial installations
• 30 mA personal-protection threshold per IEC 60364-4-41 - mandatory additional protection for socket-outlet circuits in many jurisdictions
• Halogen- and silicon-free housing - clean room and food/pharma compatible
• Bidirectional power supply position - mount with top or bottom infeed

Applications:

• Final socket-outlet circuits in residential and commercial installations (additional 30 mA personal protection per IEC 60364-4-41)
• Wet-area circuits (bathrooms, kitchens, outdoor outlets) requiring earth-leakage + overcurrent protection
• Final circuits feeding electronics, IT loads or inverter-driven equipment requiring Type A detection
• Replacement of separate MCB + RCD pairs to save panel space

Also known as: Siemens 5SU1324-7FA06, SENTRON RCBO 2P Type A C 6A 30mA, Siemens 5SU1 series RCBO 6A 30mA, 5SU13 residual current circuit breaker with overcurrent.
