Eaton 288913 Z-D02/PE-20 Gauge Ring D02 20A Fuse Size Limiter

The Eaton Z-D02/PE-20 is a D02 gauge ring accessory rated at 20 A, designed for use with D02 fuse links in low-voltage distribution systems. Supplied in blue for clear visual amperage identification, it snaps directly onto DIN rail for fast, tool-free installation. The rated uninterrupted current (Iu) is 20 A, with operation across an ambient temperature range of -25 °C to +55 °C.

Technical specifications:

• Model code: Z-D02/PE-20
• Catalog number: 288913
• Manufacturer: Eaton
• EAN: 4015082889135
• Product type: Distribution parts - gauge ring accessory
• Fuse cartridge type: D02
• Amperage rating: 20 A
• Rated uninterrupted current (Iu): 20 A
• Color: Blue
• Dimensions (W x H x D): 16.6 mm x 10.5 mm x 16.6 mm
• Weight: 1 g
• Ambient operating temperature: -25 °C to +55 °C
• Compliances: RoHS conform

Features and benefits:

• Blue color coding delivers instant visual identification of the 20 A rating across multi-circuit panels
• Snap-fit DIN rail mounting enables fast, tool-free installation and removal
• Supplied in a plastic box matching the indicator color for organized handling and storage
• 20 A rated uninterrupted current (Iu) ensures reliable continuous operation under load
• Wide ambient temperature range of -25 °C to +55 °C suits demanding industrial environments
• RoHS compliant for use in environmentally regulated installations

Applications:

• D02 fuse holder assemblies in industrial and commercial distribution boards
• Color-coded circuit identification in switchgear panels and control enclosures
• DIN rail mounted fuse systems requiring 20 A current rating
• Replacement gauge rings in existing D02 fuse installations
• New panel builds where D02 fuse links are specified at 20 A

RoHS conform. Part of the Eaton D02 fuse accessories range.

Also known as: Eaton Z-D02/PE-20, Eaton 288913, Eaton catalog 288913, Eaton model Z-D02/PE-20, Eaton D02 gauge ring 20 A, Eaton blue D02 ring.
